Fast-sailing Hasselteraak, charter or residential vessel

General
Windows: Bronze
Other:

Community Certificate for Inland Navigation Vessels: no SI 12094 B, issued in Rotterdam on 21 April 2011
and valid until 31 March 2027 for Zone 2, 3 and 4 within
Netherlands and Rhine cross traffic;
maximum of 19 passengers.

Mast and rigging certificates: issued by NBKB in Rotterdam on July 14, 2020 and
valid until December 30, 2022; sail area 220 m2 ;
gaff rigged

Accommodation
Saloons: fore cabin furnished as crew sleeping quarters; with wooden chain locker; dayroom with benches and tables and open U-shaped kitchen on port side; midship longitudinal corridor with passenger cabins on both sides (port 4x double cabin and port 2x single cabin) and sanitary rooms on port side; deckhouse on aft deck for access to engine room and simple laundry room on port side and access to aft ship; aft ship with original wooden paneling with fireplace, sleeping berth, bench and cabinets
Cabins: 4 x 2 berths and 2 x single berth. Now the cabins are single berth.
Berths: X
Engine, electrics, water
Year: Not known
Engine hours: Not known
Cooling system: Blokland box cooling
Propulsion: 50 mm 3 blade
Rig and sails
Number of masts: X
Safety
Other:

Hull construction : steel, riveted and partly welded
Transverse bulkheads : 2 pieces watertight of which engine room bulkhead with steel
watertight toggle door
skin : ca. 5 mm
bilges : partly doubled; remaining ca. 5 - 6 mm, with rounding
bottom : largely doubled; other approx. 5 - 6 mm
truss spacing : 350 mm
trusses : riveted L-profiles
various : steel railings on both sides with wooden painted
upper side;
bollards with open enclosures

FURTHER PARTICULARS
Other certificates and data:
- displacement when empty 45,508 m
3
;
- draught certificate issued by NBKB on April 12, 2022; freeboard 58 cm;
- stability calculation surveyed by Register Holland on January 9, 2008;
- drawings approved by Register Holland on 7 January 2008 concerning sail plan,
tank plan and slipway test;
- the vessel is equipped for operation mode A1 and complies with article 23.09 paragraph 1.1 of the
ROSR (31.01 of the ES-TRIN);
- the Community Certificate contains a list concerning the
transitional provisions of items that do not have to be complied with as long as they
are not changed;
- Rhine Vessel Declaration issued in Rijswijk on 19 April 2022;
- Certificate of Incorporation AIS issued April 15, 2022;
- megger test performed on July 20, 2017 (valid for 3 years);
- liquefied gas installation inspected until April 1, 2025;
